Demystifying Veeam Housekeeping: The Silent Guardian of Your Backups

Housekeeping is an automatic, background, and largely invisible maintenance process that manages the lifecycle of backup files in Veeam Backup & Replication.

This process cleans the backup chain, deletes old restore points, merges files, verifies integrity, reclaims free space, and optimizes the storage system.

“Housekeeping is a background mechanism used for the regular cleaning, merging, and verification of backup files.”

Veeam typically uses forward incremental or reverse incremental backup strategies. Over time, these strategies can lead to the following issues:

  • The backup chain becomes long and fragmented.

  • Storage space is unnecessarily consumed.

  • Restore performance degrades.

  • Silent data corruption (e.g., bit rot) goes undetected.

  • Blocks belonging to deleted VMs remain on disk.

Housekeeping exists to solve these problems. Its goal is to ensure the backup system remains sustainable, reliable, and performant.

When Does Housekeeping Run?

Housekeeping operates entirely automatically without user intervention. The default schedule is as follows:

  • Background Retention: Every 24 hours, at 00:30 (server time).

  • Health Check: Monthly, typically on the first Friday night.

  • Compact Full: Immediately after each merge operation.

  • Space Reclamation: Continuously, in the background.

These processes are not interrupted if a backup job is running. If a backup is active, housekeeping is paused and resumes after the job finishes.

What Exactly Happens in the Background?

Housekeeping is a layered, autonomous, and highly intelligent maintenance system composed of multiple sub-processes. Let's break down this process step-by-step, with micro-level technical details, delving into Veeam's internal workings.

1. Trigger
The Veeam Backup Service (VeeamBackupSvc.exe) initiates a housekeeping control loop every 4 hours. At 00:30, Background Retention is officially triggered.

2. Metadata Analysis
The system reads job configurations from the Configuration Database (SQL Server or PostgreSQL).

It then lists the current backup files for each job.
These queries gather critical information such as retention policy, GFS (Grandfather-Father-Son) settings, and the current number of restore points.

3. Chain Analysis
At this stage, the physical file system is scanned:

  • Storage Location: e.g., D:\Backup\SQL Servers Backup\

  • File Types:

    • .vbk → Full backup

    • .vib → Incremental backup

    • .vbm → Metadata (chain map, CBT data, hashes)

The .vbm file keeps track of, for each restore point:

  • Which blocks it contains

  • Their SHA1 hashes

  • The CBT (Changed Block Tracking) state

  • GFS labels

4. Retention Enforcement
Scenario: Retention = 14 points, Current = 15 points → Retention policy is triggered. (Forward Incremental Scenario)

Decision Engine:

  • The oldest incremental is identified: e.g., VBK_2025-10-09.vib

  • The number of merge points is calculated.

  • The first full backup is merged with the oldest incremental backup.

  • The oldest incremental file is deleted.

5. Compact Full – Space Cleanup
After a merge, the old .vbk file may contain blocks from VMs that have been deleted.

Compact Process:

  • A new temporary file is created: e.g., VBK_2025-10-16.vbk.compact.tmp

  • Only blocks currently in use are copied.

  • The old file is deleted.

  • The new file is renamed: e.g., VBK_2025-10-16.vbk

6. Health Check – Integrity Verification
Runs monthly, on the first Friday night:

  • All .vbk and .vib files are opened in read-only mode.

  • For each block:

    • A CRC32 checksum is calculated.

    • A SHA1 hash is calculated.

    • It is compared against the hash stored in the database ([Backup.Model.Blocks]).

  • Result:

    • If it doesn't match → Repair from the nearest healthy point is attempted.

    • If repair fails → The file is marked as "Corrupted".

7. Space Reclamation – Free Space Recovery
Runs continuously in the background:

  • CBT data cleanup.

  • Removal of .ctk files for deleted VMs.

  • Deduplication Database cleanup.

  • Veeam.Agent.exe sends a reclaim command to the storage appliance.

  • For ReFS/XFS with fast clone, deleted blocks are immediately freed.

8. Repository Maintenance

Storage Type Operations
ReFS / XFS Metadata sync, block freeing.
Object Storage If immutability is enabled, deletion is delayed until the hold expires.
SOBR (Scale-Out) Data movement between performance and capacity tiers, extent cleanup.
Dedupe Appliance Sends a maintenance mode signal.

Deduplication Appliance and the Maintenance Mode Signal: What Does It Mean in Veeam?

As mentioned earlier, the "Dedupe Appliance – Maintenance mode signal" is a compatibility mechanism used in Veeam Backup & Replication's integration with deduplication appliances (such as Dell EMC Data Domain, ExaGrid, HPE StoreOnce). It is designed to prevent conflicts during housekeeping operations. Let's explain this in detail, step by step.

1. What is a Deduplication Appliance?

  • Dedupe Appliance: These are specialized storage devices that identify and store duplicate data blocks only once. Veeam uses these devices as backup repositories.

  • Example Integrated Appliances:

    • Dell EMC Data Domain

    • ExaGrid

    • HPE StoreOnce

    • Quantum DXi

  • Advantage: Can reduce storage space by up to 90%, but they can be performance-sensitive—especially read/write operations can be slow.

  • Veeam Integration: Veeam connects directly to these appliances using their native APIs. This ensures that Veeam's own compression/deduplication does not conflict with the appliance's deduplication.

2. What is the "Maintenance Mode Signal" from Veeam?

  • The Signal: During housekeeping (e.g., merge, compact full, health check operations), Veeam sends an API call or signal to the deduplication appliance. This temporarily places the appliance into a maintenance mode.

  • Purpose: To prevent conflicts between Veeam's background housekeeping operations and the appliance's own internal maintenance tasks.

  • Example: During housekeeping, Veeam performs intensive read operations while deleting old backups or merging chains. If the appliance's own deduplication optimization runs simultaneously, performance can degrade by up to 50%.

  • How the Signal is Sent: It is handled by the Veeam.Agent.exe (transport agent). Veeam sends a "maintenance mode" command via the appliance's API → The appliance optimizes its traffic (e.g., by shortening its read queue).

  • Automatic for Integrated Appliances: Veeam automatically sends this signal for integrated appliances (see list above). For non-integrated devices, manual configuration may be required.

This is a really good explanation of how retention is managed, among other things. Thanks. Good reference.

A really great explanation of retention and how it is managed.  Great read for those just getting started with Veeam.  Thanks for sharing this Tarik.

Thank you ​@Chris.Childerhose , ​@randyweis

I think users should know what Veeam is doing in the background.

Cool post. I didn’t actually know how ever task worked.

It would be nice to have the ability to automatically clean up empty folders after a specified date from removed jobs.



If you are 100% sure no active jobs are using the folders, it can be done in powershell though.

Here is a script that can show all the empty folders on a repo.



# -------------------------------
# Script: Find-EmptyVeeamFolders.ps1
# Description: Lists empty or orphaned folders in Veeam repositories.
# Safe to run — does not delete anything.
# -------------------------------

# Load Veeam PowerShell snap-in if not already loaded
if (-not (Get-PSSnapin -Name VeeamPSSnapIn -ErrorAction SilentlyContinue)) {
    Add-PSSnapin VeeamPSSnapIn -ErrorAction SilentlyContinue
}

# ==== EDIT THIS PATH ====
$RepoPath = "D:\Backups"   # Change to your Veeam repository root path

# Get list of active repository folders from Veeam (linked to known jobs)
$knownFolders = @()
Get-VBRBackup | ForEach-Object {
    $_.GetAllStorages() | ForEach-Object {
        $path = Split-Path $_.FilePath -Parent
        if ($path -like "$RepoPath*") { $knownFolders += $path }
    }
}
$knownFolders = $knownFolders | Sort-Object -Unique

# Find all subfolders under the repo path
$allFolders = Get-ChildItem $RepoPath -Directory -Recurse

# Detect empty folders
$emptyFolders = $allFolders | Where-Object {
    (Get-ChildItem $_.FullName -Recurse -Force | Measure-Object).Count -eq 0
}

# Detect “orphaned” folders (no active Veeam jobs reference them)
$orphanedFolders = $allFolders | Where-Object {
    ($knownFolders -notcontains $_.FullName) -and
    (Get-ChildItem $_.FullName -Force | Measure-Object).Count -gt 0
}

# Output summary
Write-Host "`n=============================="
Write-Host "Empty folders found: $($emptyFolders.Count)"
Write-Host "Orphaned (unlinked) folders found: $($orphanedFolders.Count)"
Write-Host "==============================`n"

# Export results
$timestamp = Get-Date -Format "yyyyMMdd_HHmmss"
$exportPath = "C:\Temp\VeeamRepoAudit_$timestamp.csv"

$results = @()
$results += $emptyFolders | Select-Object @{n='Type';e={'Empty'}}, FullName
$results += $orphanedFolders | Select-Object @{n='Type';e={'Orphaned'}}, FullName
$results | Export-Csv $exportPath -NoTypeInformation

Write-Host "Results saved to: $exportPath"
Write-Host "Review before deleting any folders!"





Then once you review the data, you could clean up the empty folders.



# -------------------------------
# Script: Cleanup-EmptyVeeamFolders.ps1
# Description: Safely removes empty folders in a Veeam repository.
# ONLY removes folders that are completely empty.
# -------------------------------

# ==== EDIT THIS PATH ====
$RepoPath = "D:\Backups"   # Change to your Veeam repository root path

# Find all empty folders
$emptyFolders = Get-ChildItem $RepoPath -Directory -Recurse | Where-Object {
    (Get-ChildItem $_.FullName -Recurse -Force | Measure-Object).Count -eq 0
}

if ($emptyFolders.Count -eq 0) {
    Write-Host "No empty folders found. Nothing to delete."
} else {
    Write-Host "Found $($emptyFolders.Count) empty folders. Deleting now..."

    foreach ($folder in $emptyFolders) {
        try {
            Remove-Item $folder.FullName -Recurse -Force
            Write-Host "Deleted: $($folder.FullName)"
        } catch {
            Write-Warning "Failed to delete: $($folder.FullName) — $_"
        }
    }

    Write-Host "`nCleanup complete."
}
